The TP-Link RE205 AC750 is a dual-band Wi-Fi range extender designed to expand an existing wireless network into areas with weak reception. Operating on both 2.4 GHz and 5 GHz bands, it provides theoretical wireless signal rates of up to 300 Mbps and 433 Mbps respectively, making it a practical solution for improving Wi-Fi access around the home or office.
Featuring two external antennas, an intelligent signal indicator, and a compact wall-plug design, the RE205 helps simplify placement and setup. It also supports Access Point mode through its Ethernet port, TP-Link OneMesh networking with compatible routers, and convenient configuration using the TP-Link Tether app.
Key Features
- AC750 Dual-Band Wi-Fi: Supports up to 300 Mbps on 2.4 GHz and 433 Mbps on 5 GHz theoretical wireless signal rates.
- Expanded Wireless Coverage: Extends an existing Wi-Fi network into areas where the main router's signal is weak.
- Intelligent Signal Indicator: Helps identify a suitable placement location by displaying connection strength.
- Two External Antennas: Designed to support wireless signal reception and extended coverage.
- Range Extender and Access Point Modes: Extend an existing wireless network or create a wireless access point from a wired Ethernet connection.
- OneMesh and Tether Support: Create a unified Wi-Fi network with compatible OneMesh routers and manage settings through the TP-Link Tether app.
Technical Specifications
| Component | Specification |
| Brand | TP-Link |
| Model | RE205 |
| Hardware Version | V4 |
| Product Type | Wi-Fi Range Extender |
| Wi-Fi Class | AC750 |
| Wireless Standards | IEEE 802.11a/n/ac (5 GHz), IEEE 802.11b/g/n (2.4 GHz) |
| Wireless Bands | 2.4 GHz and 5 GHz |
| 2.4 GHz Signal Rate | Up to 300 Mbps (theoretical) |
| 5 GHz Signal Rate | Up to 433 Mbps (theoretical) |
| Operating Modes | Range Extender / Access Point |
| Ethernet Port | 1 × 10/100 Mbps RJ45 |
| Antennas | 2 × External Antennas |
| Mesh Compatibility | TP-Link OneMesh |
| Wireless Security | WEP, WPA/WPA2-PSK |
| Buttons | WPS, RESET |
| Plug Type | EU |
| Input Power | 100–240 V AC, 50/60 Hz |
| Maximum Power Consumption | 7.2 W |
| Dimensions (W × D × H) | 77.8 × 40 × 80 mm |
| Management | TP-Link Tether App / Web Management |
Compatibility & Important Information
- Existing Wi-Fi Network: Range Extender mode requires an existing Wi-Fi router or wireless access point. The RE205 does not provide an independent internet connection.
- OneMesh Compatibility: A compatible TP-Link OneMesh router is required to create a unified OneMesh network.
- Access Point Mode: Requires an Ethernet connection to an existing wired network.
- Ethernet Speed: The RJ45 port supports 10/100 Mbps, not Gigabit Ethernet.
- Placement: The intelligent signal indicator helps position the extender within suitable wireless range of the main router.
- Wireless Rates: AC750 is a wireless class designation. The advertised band speeds are theoretical and do not represent guaranteed internet throughput.
- Power Connection: The specified version uses an EU-style wall plug.
Package Contents
- 1 × TP-Link RE205 AC750 Wi-Fi Range Extender
- 1 × Quick Installation Guide
