Catastrophic Event Protection:
- SurgeArrest components such as MOVs and Thermal fuse ensure instantaneous reaction to lightning strikes and wiring faults. If the surge components are damaged due to power spike or over voltage, excess power cannot reach your equipment. Unlike the APC SurgeArrest products, most surge suppressors continue to let power through even after circuits have been damaged, leaving your equipment exposed to other damaging surges.
Fail Safe Mode:
- Most other surge suppressors continue to let power through even after their circuits have been damaged, leaving your equipment exposed to future surges. APC´s SurgeArrest fail safe, which means that once the circuit of an APC SurgeArrest has been compromised the unit disconnects equipment from the power supply ensuring that no damaging surges reach your equipment.
Protection:
Lightning and Surge Protection:
- To prevent damage to your equipment from electric power surges and spikes.
Noise Filtering:
- Attenuates EMI/RFI line noise that can cause data errors and keyboard lockups, ensuring better performance of protected equipment.
Safety-Agency Approved Surge Protector:
- All the APC surge protectors undergo stringent testing to comply with global and local agency safety requirements.
Overview
| Lead time |
Usually in Stock |
Main
| Main Input Voltage |
220...250 V AC |
| Main Output Voltage |
220...250 V AC |
| Input Connection Type |
BS1363A British |
| Cable length |
1.5 m |
Physical
| Colour |
Black |
| height |
371.8 mm |
| Width |
62.9 mm |
| Depth |
40 mm |
| Net weight |
0.54 kg |
| mounting support |
Wall-mount |
| Mounting preference |
No preference |
| Mounting mode |
Not rack-mountable |
Input
| Network frequency |
50/60 Hz +/- 5 Hz |
| plug standard |
British |
Output
| Number of power socket outlets |
5 |
| outlet standard |
Universal |
| Outlet standard |
Universal |
Environmental
| ambient air temperature for operation |
0…40 °C |
| Relative humidity |
0…95 % |
| Operating altitude |
0...3000 m |
| Ambient air temperature for storage |
-15…45 °C |
| Storage altitude |
0…15000 m |
Surge Protection and Filtering
| Surge energy rate |
700 J |
Packing Units
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
40.2 cm |
| Package 1 Width |
12 cm |
| Package 1 Length |
5.2 cm |
| Package 1 Weight |
640 g |
| SCC14 |
10731304453281 |
