Processor Brand:

Intel

Processor Socket:

LGA 1700

Supported Processor Generation:

14th Gen Intel Core13th Gen Intel Core12th Gen Intel CorePentium GoldCeleron

Chipset Model:

Intel Z790 Express

Memory Type:

DDR5

Memory Speed:

Up to 8266 MT/s (OC)

Memory Slots:

4 x DIMM

Max Memory Capacity:

256GB

Memory Channel:

Dual Channel

XMP Support:

Extreme Memory Profile (XMP)

Integrated Graphics:

Intel HD Graphics

Display Outputs:

USB-C (DP, up to 4096x2304@60Hz)USB-C (DP, up to 1920x1080@30Hz)HDMI 2.1 (up to 4096x2160@60Hz)

Audio Codec:

Realtek ALC1220-VB

Audio Channels:

7.1 Channel

SPDIF Support:

Yes

LAN:

Realtek 5GbE

Wireless:

Wi-Fi 7

Bluetooth:

Bluetooth 5.4

PCIe x16 (CPU):

1 x PCIe 5.0 x16

PCIe x16 (Chipset):

1 x PCIe 4.0 x41 x PCIe 4.0 x4 (BIOS dependent)

M.2 Slots:

5 x M.2

PCIe 5.0 M.2:

1 x PCIe 5.0 x4

SATA:

4 x SATA 6Gb/s

RAID Support:

RAID 0RAID 1RAID 5RAID 10

USB-C:

USB 3.2 Gen 2x2USB 3.2 Gen 2USB 2.0 (DP support)

USB Type-A:

USB 3.2 Gen 2USB 3.2 Gen 1USB 2.0

Power Connectors:

24-pin ATX2 x 8-pin CPU

Fan Headers:

7 x Fan / Pump Headers

RGB Headers:

3 x Addressable RGB Gen21 x RGB Header

USB Ports:

USB 2.0USB 3.2 Gen 1USB 3.2 Gen 2USB-C Gen 2x2

Display:

HDMIDisplayPort

Networking:

RJ-45

Audio:

Optical S/PDIF OutAudio Jacks

BIOS Type:

AMI UEFI

BIOS Features:

Q-FlashQ-Flash Plus

OS:

Windows 11 64-bit

Form Factor:

ATX

Dimensions:

30.5 x 24.4 cm
