ASRock Z890 Pro RS LGA 1851 Intel Core Ultra Z890 ATX Motherboard

Motherboard Brand:

ASRock

Motherboard Model:

Z890 Pro RS

CPU Socket Type:

LGA 1851

CPU Type:

Intel Core Ultra Processors (Series 2)

Chipset:

Intel Z890

Form Factor:

ATX

Number Of Memory Slots:

4 x DDR5

Memory Type:

DDR5

Maximum Memory Supported:

256GB

Channel Supported:

Dual Channel

Maximum Memory Speed:

Up to 9066+ MHz (OC)

Memory Performance Profile:

Intel XMP 3.0

PCI Express 5.0 x16:

1 x PCIe 5.0 x16

PCI Express 4.0 x4:

2 x PCIe 4.0 x4

PCI Express 4.0 x1:

1 x PCIe 4.0 x1

SATA:

4 x SATA 6Gb/s

M.2 Slots:

4

M.2 PCIe Gen5:

1 x PCIe Gen5 x4

M.2 PCIe Gen4:

3 x PCIe Gen4 x4

SATA RAID:

RAID 0, RAID 1, RAID 5, RAID 10

NVMe RAID:

RAID 0, RAID 1, RAID 5, RAID 10

Audio Chipset:

Realtek ALC897

Audio Channels:

7.1 CH HD Audio

Audio Feature:

Nahimic Audio

LAN Chipset:

Dragon RTL8125BG

LAN Speed:

2.5Gbps

HDMI:

1

DisplayPort:

1 x DisplayPort 1.4

Thunderbolt:

2 x Thunderbolt 4 Type-C (40Gb/s)

USB 3.2 Gen2 Type-A:

1 x 10Gb/s

USB 3.2 Gen1:

2

USB 2.0:

4

LAN:

1 x RJ-45

Audio Jacks:

Line In / Front Speaker / Microphone

BIOS Flashback:

1 x BIOS Flashback Button

USB 2.0 Headers:

2

USB 3.2 Gen1 Headers:

2

Front USB Type-C:

1 x USB 3.2 Gen2x2 (20Gb/s)

RGB Header:

1

Addressable RGB Headers:

3

CPU Fan Connectors:

2

Chassis Fan Connectors:

5

AIO Pump Connector:

1

Front Panel Audio:

1

BIOS Type:

256Mb AMI UEFI Legal BIOS with GUI Support

BIOS Flashback:

Supported

Windows 11:

Supported

Form Factor:

ATX

Dimensions:

12.0 x 9.6 inches

Main Power Connector:

1 x 24-pin ATX

CPU Power Connectors:

2 x 8-pin 12V
